Estou com um problem em um compute instance no OCI, e o support me solicitou um OSWatcher para analisar o ambiente.
Diante disso como eu não tinha nenhum documento facilitando uma busca rápida, resolvi escrever este post para pode ajudar outras pessoas que no momento de necessitarem de uma consulta rápida não precisem ficar se matando para achar as informações.
Vamos lá para nossa instalação.
Relatórios de desempenho do Oracle OSWatcher
A ferramenta OSWatcher é uma ferramenta muito interessante que coleta e mantém dados estatísticos dos recursos do sistema operacional periodicamente e nos reporta. Você pode baixar e usar o software OSWatcher do suporte Oracle.
OSWatcher (Doc ID 301137.1)
OS Watcher User’s Guide (Doc ID 1531223.1)
A ferramenta OSWatcher executa alguns comandos como TOP, iostat, vmstat, netstat em determinados intervalos e mantém esses dados no servidor.
Instalação do OSWatcher
Passo 1: Baixe o OSWatcher e extraia-o conforme a seguir.
[opc@vm-blog oswbb]$ ll total 5132 -rw-rw-r-- 1 opc opc 5253120 Dec 12 20:49 oswbb840.tar [opc@vm-blog oswbb]$ [opc@vm-blog oswbb]$ tar -xvf oswbb840.tar oswbb/ oswbb/uncpr.bat oswbb/sarsub.sh oswbb/psmemsub.sh oswbb/stopOSWbb.sh oswbb/analysis/ oswbb/piddsub.sh oswbb/arpsub.sh oswbb/docs/ oswbb/docs/OSWatcher/ oswbb/docs/OSWatcher/oswbb_README.txt oswbb/docs/OSWatcher/RAC_Traceroute_Automation_Readme.txt oswbb/docs/OSWatcher/OSWatcherUserGuide.html oswbb/docs/The_Analyzer/ oswbb/docs/The_Analyzer/AnalyzerUserGuide.html oswbb/docs/The_Analyzer/oswbba_README.txt oswbb/docs/OSWatcherOverview_840.pdf oswbb/Exampleprivate.net oswbb/tmp/ oswbb/oswbba.jar oswbb/oswib.sh oswbb/ltop.sh oswbb/archive/ oswbb/oswnet.sh oswbb/call_uptime.sh oswbb/OSWatcher.sh oswbb/vmsub.sh oswbb/pidsub.sh oswbb/src/ oswbb/src/js/ oswbb/src/js/bootstrap.js oswbb/src/js/modernizr.js oswbb/src/js/jquery-2.1.4.min.js oswbb/src/js/THIRDPARTYLICENSE.txt oswbb/src/js/jquery.lightbox.js oswbb/src/js/tabs.js oswbb/src/js/scripts.js oswbb/src/js/templatemo_custom.js oswbb/src/Thumbs.db oswbb/src/fonts/ oswbb/src/fonts/FontAwesome.otf oswbb/src/fonts/fontawesome-webfont.woff oswbb/src/fonts/fontawesome-webfont.woff2 oswbb/src/fonts/fontawesome-webfont.eot oswbb/src/fonts/fontawesome-webfont.ttf oswbb/src/fonts/fontawesome-webfont.svg oswbb/src/META-INF/ oswbb/src/META-INF/application-client.xml oswbb/src/images/ oswbb/src/images/Thumbnail_Placeholder.png oswbb/src/images/next.png oswbb/src/images/bx_loader.gif oswbb/src/images/close.png oswbb/src/images/loading.gif oswbb/src/images/previous.png oswbb/src/css/ oswbb/src/css/templatemo_misc.css oswbb/src/css/bootstrap.min.css oswbb/src/css/style.css oswbb/src/css/font-awesome.min.css oswbb/src/css/templatemo_style.css oswbb/src/css/animate.css oswbb/src/pro.htm oswbb/src/oswbba_input.txt oswbb/topaix.sh oswbb/xensub.sh oswbb/iosub.sh oswbb/oswsub.sh oswbb/nfssub.sh oswbb/xtop.sh oswbb/genprvnet.sh oswbb/oswrds.sh oswbb/call_sar.sh oswbb/call_du.sh oswbb/ifconfigsub.sh oswbb/mpsub.sh oswbb/Example_extras.txt oswbb/locks/ oswbb/OSWatcherFM.sh oswbb/tar_up_partial_archive.sh oswbb/data/ oswbb/tar_up_full_archive.sh oswbb/gif/ oswbb/startOSWbb.sh [opc@vm-blog oswbb]$ O conteúdo do OSWatcher é o seguinte. [opc@vm-blog oswbb]$ cd oswbb/ [opc@vm-blog oswbb]$ ll total 472 drwxr-xr-x 2 opc opc 6 Nov 19 2019 analysis drwxr-xr-x 2 opc opc 6 Nov 19 2019 archive -rwxrwxr-x 1 opc opc 546 Jul 15 2019 arpsub.sh -rwxrwxr-x 1 opc opc 67 Jul 15 2019 call_du.sh -rwxrwxr-x 1 opc opc 68 Jul 15 2019 call_sar.sh -rwxrwxr-x 1 opc opc 71 Jul 15 2019 call_uptime.sh drwxrwxr-x 2 opc opc 6 Nov 19 2019 data drwxrwxr-x 4 opc opc 76 Nov 19 2019 docs -rwxrwxr-x 1 opc opc 665 Jul 15 2019 Example_extras.txt -rwxrwxr-x 1 opc opc 1864 Jul 15 2019 Exampleprivate.net -rwxrwxr-x 1 opc opc 3990 Jul 15 2019 genprvnet.sh drwxrwxr-x 2 opc opc 6 Nov 19 2019 gif -rwxrwxr-x 1 opc opc 795 Jul 15 2019 ifconfigsub.sh -rwxrwxr-x 1 opc opc 743 Jul 15 2019 iosub.sh drwxrwxr-x 2 opc opc 6 Nov 19 2019 locks -rwxrwxr-x 1 opc opc 1507 Jul 15 2019 ltop.sh -rwxrwxr-x 1 opc opc 542 Jul 15 2019 mpsub.sh -rwxrwxr-x 1 opc opc 745 Jul 15 2019 nfssub.sh -rwxrwxr-x 1 opc opc 8035 Jul 15 2019 OSWatcherFM.sh -rwxrwxr-x 1 opc opc 55817 Nov 19 2019 OSWatcher.sh -rw-r--r-- 1 opc opc 289876 Nov 19 2019 oswbba.jar -rwxrwxr-x 1 opc opc 414 Jul 15 2019 oswib.sh -rwxrwxr-x 1 opc opc 579 Jul 15 2019 oswnet.sh -rwxrwxr-x 1 opc opc 825 Jul 15 2019 oswrds.sh -rwxrwxr-x 1 opc opc 524 Jul 15 2019 oswsub.sh -rwxrwxr-x 1 opc opc 561 Jul 15 2019 piddsub.sh -rwxrwxr-x 1 opc opc 565 Jul 15 2019 pidsub.sh -rwxrwxr-x 1 opc opc 1481 Jul 15 2019 psmemsub.sh -rwxrwxr-x 1 opc opc 557 Jul 15 2019 sarsub.sh drwxrwxr-x 7 opc opc 126 Nov 19 2019 src -rwxrwxr-x 1 opc opc 2574 Jul 15 2019 startOSWbb.sh -rwxrwxr-x 1 opc opc 752 Jul 15 2019 stopOSWbb.sh -rwxrwxr-x 1 opc opc 819 Jul 15 2019 tar_up_full_archive.sh -rwxrwxr-x 1 opc opc 8234 Jul 15 2019 tar_up_partial_archive.sh drwxr-xr-x 2 opc opc 6 Nov 19 2019 tmp -rwxrwxr-x 1 opc opc 527 Jul 15 2019 topaix.sh -rwxrwxr-x 1 opc opc 414 Nov 13 2019 uncpr.bat -rwxrwxr-x 1 opc opc 545 Jul 15 2019 vmsub.sh -rwxrwxr-x 1 opc opc 571 Jul 15 2019 xensub.sh -rwxrwxr-x 1 opc opc 1486 Jul 15 2019 xtop.sh [opc@vm-blog oswbb]$
Passo 2: Para iniciar a ferramenta OSWatcher, execute startOSWbb.sh como a seguir.
startOSW.sh <SnapshotInterval > <ArchiveInterval>
Por exemplo; Se iniciarmos o OSWatcher como sh startOSWbb.sh 60 10, então o OSWatcher vai coletar dados a cada 60 segundos e manterá esses dados por 10 horas.
Por default ele inicia a coleta com intervalo de 30 segundos e mantém os logs por 48 horas.
opc@vm-blog oswbb]$ Info...You did not enter a value for snapshotInterval. Info...Using default value = 30 Info...You did not enter a value for archiveInterval. Info...Using default value = 48 Setting the archive log directory to/oswbb/oswbb/archive Testing for discovery of OS Utilities... VMSTAT found on your system. IOSTAT found on your system. MPSTAT found on your system. IP found on your system. TOP found on your system. Warning... /proc/slabinfo not found on your system. Check to see if this user has permission to access this file. PIDSTAT found on your system. NFSIOSTAT found on your system. Warning... TRACEROUTE not found on your system. No TRACEROUTE data will be collected. Discovery of CPU CORE COUNT CPU CORE COUNT will be used by oswbba to automatically look for cpu problems CPU CORE COUNT = 4 VCPUS/THREADS = 4 Discovery completed. Starting OSWatcher v8.4.0 on Tue Dec 12 21:02:21 GMT 2023 With SnapshotInterval = 30 With ArchiveInterval = 48 OSWatcher - Written by Carl Davis, Center of Expertise, Oracle Corporation For questions on install/usage please go to MOS (Note:301137.1) Data is stored in directory: /oswbb/oswbb/archive Starting Data Collection... oswbb heartbeat:Tue Dec 12 21:02:26 GMT 2023 oswbb heartbeat:Tue Dec 12 21:02:56 GMT 2023
Você pode parar o OSWatcher através do comando
[opc@vm-blog oswbb]$ ./stopOSWbb.sh [opc@vm-blog oswbb]$
Agora podemos analisar os dados
[opc@vm-blog oswbb]$ java -jar oswbba.jar -i archive Starting OSW Analyzer V8.4.0 OSWatcher Analyzer Written by Oracle Center of Expertise Copyright (c) 2019 by Oracle Corporation Parsing Data. Please Wait... Scanning file headers for version and platform info... Parsing file vm-blog_pidstat_23.12.12.2100.dat ... Parsing file vm-blog_iostat_23.12.12.2100.dat ... This directory already exists. Rewriting... Parsing file vm-blog_vmstat_23.12.12.2100.dat ... Parsing file vm-blog_netstat_23.12.12.2100.dat ... Parsing file vm-blog_top_23.12.12.2100.dat ... Parsing file vm-blog_ps_23.12.12.2100.dat ... Parsing Completed. Enter 1 to Display CPU Process Queue Graphs Enter 2 to Display CPU Utilization Graphs Enter 3 to Display CPU Other Graphs Enter 4 to Display Memory Graphs Enter 5 to Display Disk IO Graphs Enter 61 to Display Individual OS Process I/O RPS Graphs Enter 62 to Display Individual OS Process I/O WPS Graphs Enter 63 to Display Individual OS Process Percent User CPU Graphs Enter 64 to Display Individual OS Process Percent System CPU Graphs Enter 65 to Display Individual OS Process Percent Total CPU (User + System) Graphs Enter 66 to Display Individual OS Process Percent Memory Graphs Enter GP to Generate Individual Process Profile Enter GC to Generate All CPU Gif Files Enter GM to Generate All Memory Gif Files Enter GD to Generate All Disk Gif Files Enter GN to Generate All Network Gif Files Enter L to Specify Alternate Location of Gif Directory Enter Z to Zoom Graph Time Scale (Does not change analysis dataset) Enter B to Returns to Baseline Graph Time Scale (Does not change analysis dataset) Enter R to Remove Currently Displayed Graphs Enter X to Export Parsed Data to Flat File Enter S to Analyze Subset of Data(Changes analysis dataset including graph time scale) Enter A to Analyze Data Enter D to Generate DashBoard Enter Q to Quit Program
Para este exemplo selecionei a opção 1
Para este exemplo selecionei a opção
Também podemos gerar um Dashboard para analise.
Please Select an Option:D Enter a unique analysis/dashboard directory name or enter <CR> to accept default name: A new analysis file analysis/vm-blog_Dec12050009_1702416975/analysis.txt has been created. Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Run_Queue.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Run_Adjusted_Queue.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Block_Queue.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_HB.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_PS_Processes.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Cpu_Idle.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Cpu_Util.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Cpu_System.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Cpu_User.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Cpu_Wa.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Cpu_Interrupts.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Context_Switches.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Memory_Swap.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Memory_Free.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Memory_Page_In_Rate.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Memory_Page_Out_Rate.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Cpu_Wa.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_Block_Queue.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_IO_ST.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_IO_AW.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_IO_PB.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_IO_RPS.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_IO_WPS.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_OS_IO_TPS.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ lo_rx_ok.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ lo_rx_err.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ lo_rx_drp.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ lo_rx_ovr.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ lo_tx_ok.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ lo_tx_err.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ lo_tx_drp.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ lo_tx_ovr.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ enp0s6_rx_ok.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ enp0s6_rx_err.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ enp0s6_rx_drp.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ enp0s6_rx_ovr.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ enp0s6_tx_ok.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ enp0s6_tx_err.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ enp0s6_tx_drp.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_link_ enp0s6_tx_ovr.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_IpOutRequests.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_IpInReceives.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_IpFragCreates.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_IpFragOKs.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_IpInDiscards.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_IpReasmFails.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_ip_fragments_in_rate.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_ip_fragments_out_rate.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_UdpInDatagrams.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_UdpOutDatagrams.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_UdpInErrors.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_UdpInCsumErrors.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_UdpRcvbufErrors.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_UdpSndbufErrors.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_TcpInSegs.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_TcpOutSegs.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_TcpRetransSegs.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_TcpOutRsts.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_TcpEstabResets.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_TcpAttemptFails.jpg Generating file analysis/vm-blog_Dec12050009_1702416975/dashboard/generated_files/OSWg_tcp_retran_error_rate.jpg Files written to the analysis directory.
Onde é Gerado um relatório no final da analise.
Espero que isso possa te ajudar em algum momento.
Até a próxima.
